Spinder Baseline self-locking feed front

Baseline self-locking feed front

Simple but strong, these are the Baseline self-locking feed fronts. Fitted with the closed upper section with hidden locking mechanism, as is a characteristic feature of Spinder. Only the push button for releasing the locked-up cow sticks out from the top of the profile. No parts where collars can be caught!

Available for large stock as well as for heifers, young stock and calves. Various feeding place widths and matching heights. This allows the animals to get used to the feed front from an early age. Fitted with the Spinder plastic movable bar stopper; nice and quiet, and with a drop pin in the catching bar to prevent the catching of the collars.

Important features:

The central operating handle allows you to open or close the feed front up to 30 m in one move.

  • The central operating handle can be used to set the entire feed front in the locking position.
  • Great catching performance thanks to the light-acting locking mechanism.
  • The animals are unable to release themselves since the locking mechanism is entirely hidden in the upper section.
  • When closed, it will be possible to release the individual animals with a simple push of a button.
  • The central operating handle can be used to release all animals in one move.
  • Using the optional Indivast locking mechanism, the animals can be individually secured in the feed front.

  • low-noise
  • locking mechanism is entirely hidden
  • ear tag friendly
  • easy operation
  • Baseline self-locking feed front
  • Baseline self-locking feed front
  • Baseline self-locking feed front
  • Baseline self-locking feed front

Specifications Baseline

Various dimensions

The Baseline self-locking feed front is available in various sections:

  • For large stock: from 2 (134 cm) to 5 (325 cm) feed openings
  • For heifers: from 2 (119 cm) to 6 (325 cm) feed openings
  • For young stock: from 2 (110 cm) to 7 (325 cm) feed openings
  • For calves: from 3 (120 cm) to 9 (325 cm) feed openings

The standard length of a feed front section is 325 cm. However, several sizes are available, depending on the desired number of feed openings and the feeding place width.

By combining feed front sections and attachments, almost all truss sizes can be effectively filled in.

Table baseline

Mounting to the 2 1/2" support posts is done with the universal fasteners. It is possible to increase the length of a feed front section by 5 cm and if this is not sufficient, Spinder have longer fastening parts available.

By mounting a so-called hinge assembly, any feed front section can be turned into a rotating gate. The locking mechanism of a rotating feed front is operated separately.

Optional accessories

  • support post
  • protective sleeve
  • floor mounted support post
  • stopper
  • feed front fasteners
  • operating handle
  • hinge assembly and castor wheel for rotating gate


All information about the Baseline feedfront can be found in our eating catalogue

Specifications Baseline

Technical drawings

Technical drawings are available for installing the Baseline self-locking feed front. Click on the link below to download the pdf file.
